Crane Bodies

Need crane parts for your Crane Bodies? Check out our  >>Parts Website

Reading Truck Bodies

The Master Mechanic™ Series body includes more standard features and benefits than our competitors’ standard production bodies — Feature Superior + Price Competitive = best overall value available.

Heavy-duty Master Mechanic™ Series Crane Bodies are designed and manufactured to withstand the harshest environments and most demanding applications in field use while providing the user with the highest quality, most user-friendly versatile, functional, and safe body available.

Action can upfit the Heavy-duty Master Mechanic™ Series Crane Bodies which are designed and manufactured to withstand the harshest environments and most demanding applications in field use while providing the user with the highest quality, most user-friendly versatile, functional, and safe body available.12-Series

The Master Mechanic™ Series 12 Series crane bodies are built for up to a 3,200 lb. crane.  Recommended chassis: Class III  (F-350, 3500HD, Ram 3500, etc.)

Body Specifications
Reading Master Mechanic™ Series MM112 heavy-duty service body package
60” cab-to-axle, 108” length, total width is 96”, cargo width is 52”.
Compartment heights: 42” on both road & curbside compartments
Flush mount doors with internal hidden hinges
D-ring handles with 3-point contact and codeable lock cylinders
Redi-Safe non-skid application on cargo floor, top, and backs of compartments, workbench bumper and front of the body
Four integrated tie-downs in the bed of the body
Interior LED dome lighting in compartments
4 exterior work lights with 360-degree rotation on head and base
20” workbench bumper with receiver hitch and 7-way trailer plug

  • Master Mechanic™ Series 5-drawer unit in RS first compartment
  • One bolt bin drawer RS horizontal compartment
  • 20” workbench bumper
  • Infinitely adjustable shelving built on unistrut channel mounts giving the user the control to put the shelves where they want them. They’re not pre-slotted like the majority of the bodies in the market.
  • Modular design allows for easier and less expensive repair and replacement of damaged components.
  • Heavy-duty trade plate covers the entire floor, bed walls and tops of compartments on the bed. It is also overlaid on the front of the compartment panels.
  • D-Ring handles accept a fully-gloved hand and has codeable lock cylinders that offer 10,000 unique codes.
  • The flush mount doors give the body a clean appearance and a smooth surface for applying company graphics. It also creates minimal pry points for added security.
  • The external lighting gives the user 360 degrees of pivotable lighting. Completely weather resistant.

Compartment Drawers and Shelving
Curb-side Compartments: Two fully adjustable shelves and welder’s supply drawer in the front compartment. One fully adjustable shelf in the horizontal compartment. Rear compartment open for crane controls and reinforcement.
Road-side Compartments: Master Mechanic™ Series 5-drawer unit in the front compartment. Bolt bin in the horizontal compartment, including full-width top shelf assembly. Two fully adjustable shelves in the rear compartment.

For more information regarding the Reading line of crane bodies please call our sales team at 800-330-1229 or fill out our contact form.

Action can upfit the Heavy-duty Master Mechanic™ Series Crane Bodies which are designed and manufactured to withstand the harshest environments and most demanding applications in field use while providing the user with the highest quality, most user-friendly versatile, functional, and safe body available.25-Series

The Master Mechanic™ Series 25 Series crane bodies are built for up to a 5,000 lb. crane. Recommended chassis: Class IV  (F-450, 4500HD, Ram 4500, etc.)

Body Specifications
Reading Master Mechanic™ Series MM225 heavy-duty service body package
84” cab-to-axle, 131” length, total width is 96”, cargo width is 52”.
Compartment heights: 60” tall first & second road & curbside compartments , 46” heights on remaining road & curbside compartments
Flush mount doors with internal hidden hinges
D-ring handles with 3-point contact and codeable lock cylinders
Redi-Safe non-skid application on cargo floor, top, and backs of compartments, workbench bumper and front of the body
Six integrated tie-downs in the bed of the body
Interior LED dome lighting in compartments
4 exterior work lights with 360-degree rotation on head and base
20” workbench bumper with receiver hitch and 7-way trailer plug

Features

  • Master Mechanic™ Series 5-drawer units in first & second RS compartments
  • Bolt bin in RS horizontal compartment
  • Welder’s supply drawer and two fully adjustable shelves in CS first compartment
  • O/A bracket in CS second compartment
  • 20” workbench bumper
  • Automotive grade rubberized undercoating provides superior protection against foreign matter damaging the understructure of the body.
  • The roll-on Redi-Safe non-skid application won’t get slick when soiled or wet. It will not ignite when used in welding applications and is easily repairable if damaged.
  • True 3-point locking when the handle is in the closed position.

Compartment Drawers and Shelving
Curb-side Compartments: Two fully adjustable shelves and welder’s supply drawer in the front compartment. O/A bracket in the second compartment. One fully adjustable shelf in the horizontal compartment. Rear compartment open for crane controls and reinforcement.
Road-side Compartments: One Master Mechanic™ Series 5-drawer unit in both first & second compartments. Bolt bin in the horizontal compartment, including full-width top shelf assembly. Two fully adjustable shelves in the rear compartment.

For more information regarding the Reading line of crane bodies please call our sales team at 800-330-1229 or fill out our contact form.

Action can upfit the Heavy-duty Master Mechanic™ Series Crane Bodies which are designed and manufactured to withstand the harshest environments and most demanding applications in field use while providing the user with the highest quality, most user-friendly versatile, functional, and safe body available.45-Series

The Master Mechanic™ Series 45 Series crane bodies are built for up to a 7,500 lb. crane. Recommended chassis: Class V  (F-550, 5500HD, Ram 5500, etc.)
Body Specifications
Reading Master Mechanic™ Series MM245 heavy-duty service body package
84” cab-to-axle, 131” length, total width is 96”, cargo width is 52”.
Compartment heights: 60” tall first & second road & curbside compartments , 46” heights on remaining road & curbside compartments
Flush mount doors with internal hidden hinges
D-ring handles with 3-point contact and codeable lock cylinders
Redi-Safe non-skid application on cargo floor, top, and backs of compartments, workbench bumper and front of the body
Six integrated tie-downs in the bed of the body
Interior LED dome lighting in compartments
4 LED exterior work lights with 360-degree rotation on head and base
Workbench storage bumper with receiver hitch

Features

  • Ribbed inner door and floor panels give the body added strength and rigidity.
  • Every body in the Master Mechanic™ Series is built with a minimum of 2 cross-members, reinforcing the substructure, unlike any other body on the market.
  • 60” tall first & second compartments on CS & RS
  • Master Mechanic™ Series 5-drawer units in first & second RS compartments
  • Bolt bin in RS horizontal compartment
  • Welder’s supply drawer in CS first compartment
  • O/A bracket in CS second compartment
  • Workbench storage bumper w/ integrated receiver tube & D-ring safety hooks

Compartment Drawers and Shelving
Curb-side Compartments: Two fully adjustable shelves and welder’s supply drawer in the front compartment. O/A bracket in the second compartment. One fully adjustable shelf in the horizontal compartment. Rear compartment open for crane controls and reinforcement.
Road-side Compartments: One Master Mechanic™ Series 5-drawer unit in both first & second compartments. Bolt bin in the horizontal compartment, including full-width top shelf assembly. Two fully adjustable shelves in the rear compartment.

For more information regarding the Reading line of crane bodies please call our sales team at 800-330-1229 or fill out our contact form.

Action can upfit the Heavy-duty Master Mechanic™ Series Crane Bodies which are designed and manufactured to withstand the harshest environments and most demanding applications in field use while providing the user with the highest quality, most user-friendly versatile, functional, and safe body available.78-Series

The Master Mechanic Series 78 Series crane bodies are built for up to a 12,000 lb. crane. Recommended chassis: Class VI  (F-650, F-750, Peterbilt, Kenworth, etc.)

Body Specifications
84” cab-to-axle, 133” length, total width is 96”, cargo width is 52”.
Compartment heights: 60” tall compartments on road & curbside
Flush mount doors with internal hidden hinges
D-ring handles with 3-point contact and codeable lock cylinders
Redi-Safe non-skid application on cargo floor, top, and backs of compartments, workbench bumper and front of the body
Six integrated tie-downs in the bed of the body
Interior LED dome lighting in compartments
4 exterior work lights with 360-degree rotation on head and base
23” workbench bumper with receiver hitch and 7-way trailer plug

Features

  • Pickup style slam-action tailgate with polished stainless steel handle and double-panel construction. Features stainless steel knee braces, locking rods, hinge rods and striker channels. Knee braces are removable and protect against rust and corrosion while allowing the tailgate to swing down completely.
  • The tie-downs are fully integrated into the substructure of the body and flush with the cargo floor providing an unobstructed bed surface.
  • Master Mechanic™ Series 5-drawer units in first & second RS compartments
  •  Bolt bin in RS horizontal compartment
  •  Welder’s supply drawer and two fully adjustable shelves in CS first compartment
  •  O/A bracket in CS second compartment
  •  23” workbench bumper

Compartment Drawers and Shelving
Curb-side Compartments: Two fully adjustable shelves and welder’s supply drawer in the front compartment. O/A bracket in the second compartment. One fully adjustable shelf in the horizontal compartment. Rear compartment open for crane controls and reinforcement.
Road-side Compartments: One Master Mechanic™ Series 5-drawer unit in both first & second compartments. Bolt bin in the horizontal compartment, including full-width top shelf assembly. Two fully adjustable shelves in the rear compartment.

For more information regarding the Reading line of crane bodies please call our sales team at 800-330-1229 or fill out our contact form.

Action can upfit the Cranemaster service truck bodies provide the structural integrity required for safe crane operation in a variety of terrain and conditions along with expansive compartment space for your crew. Cranemaster service truck bodies provide the structural integrity required for safe crane operation in a variety of terrain and conditions along with expansive compartment space for your crew. They feature an easy-mount understructure forward of the rear axle, a ½-inch-thick crane compartment top plate, and a crank-down pull-out outrigger for added security. Built with premium A60 galvannealed steel construction and Reading’s exclusive Triple Protection E-Coat primer and powder coat finish, your Cranemaster truck body will provide years of safe, heavy-duty performance in even the most challenging environments Standard features including heavy-gauge double-panel doors, Reading’s iconic heavy-duty slam-action tailgate, exclusive galvanized bumpers and a 12-gauge steel treadplate cargo area. Their Aluma-Fill® fuel cup, Dual-Pro® door seals and patented hidden hinges are also included as standard equipment on all Cranemaster service bodies.

Cranemaster 3200

The Cranemaster 3200 supports 1,000 to 3,200-pound capacity cranes. It is designed for a 10,000-pound GVWR chassis with 56” to 84” Cab-to-Axle measurements and comes in four models:

  • 98SW
  • 108SW
  • 108DW
  • 132DW

For more information regarding the Reading line of crane bodies please call our sales team at 800-330-1229 or fill out our contact form.

Cranemaster 6000

The Cranemaster 6000 supports a 6,000-pound capacity crane and requires a 15,000-pound GVWR chassis with 60″ to 84″ Cab-to Axle measurements. A vented oxygen and acetylene bottle compartment with chain hold-downs for high bottle storage is included on standard models. It is available in two lengths:

  • CM6-108A – 108″ long
  • CM6-108A – 108″ long

For more information regarding the Reading line of crane bodies please call our sales team at 800-330-1229 or fill out our contact form.

Cranemaster 8000

The Cranemaster 8000 supports an 8,000-pound capacity crane on a 21,000-33,000-pound GVWR chassis with 60″ and 84″ Cab-to-Axle measurements. Like the Cranemaster 6000, it features a vented oxygen and acetylene bottle compartment with chain hold-downs. It is available in two lengths:

  • CM8-110A – 110″ long
  • CM8-134A – 134″ long

For more information regarding the Reading line of crane bodies please call our sales team at 800-330-1229 or fill out our contact form.

Venturo

Venturo Crane Bodies are designed and manufactured for Venturo service cranes.  They provide the optimum foundation for the crane and for your work truck. Venco Venturo manufacturers rugged and strong crane bodies.  They are built reliable and long-lasting. Their 25,000 FT-LB, 40,000 FT-LB, 50,000 FT-LB and 66,000 FT-LB crane bodies are designed to provide enough storage while boosting capacity to lift your maximum loads.

Action customizes Venturo crane bodies which provide the optimum foundation for the crane and for your work truck. Venco Venturo manufacturers rugged and strong crane bodies.

Venturo HT66 Crane Body

The HT66 Crane Service Body supports the Venturo service cranes up to 66,000 FT-LBS on a 30,000 GVWR chassis. Product features:
D-ring cargo tie downs installed in the cargo floor with a 5,000 lb maximum capacity (6-8 depending on body length)
10-guage, diamond-plate steel cargo floor, sides and compartment tops provide extreme durability and secure auxiliary equipment mounting
Bulkhead and wheel well panels constructed of 12-guage Jet Kote ASTM A-60 steel sheet
All stainless steel continuous hinges for unmatched security

For more information regarding the Venturo line of crane bodies please call our sales team at 800-330-1229 or fill out our contact form.

Action customizes Venturo crane bodies which provide the optimum foundation for the crane and for your work truck. Venco Venturo manufacturers rugged and strong crane bodies.

HT50 Crane Body

The HT50 Crane Service Body supports the Venturo service cranes up to 50,000 FT-LBS on Class 6 (19,501 – 26,000 lbs GVWR) chassis.
Product features:
Three-point keyed-alike premium ergonomic Eberhard compression door handles for increased ease of use Eberhard compression door handles for increased ease of use
Unobstructed reinforced compartment for 25,000, 40,000, 50,000 and 66,000 FT-LB cranes
Dual weather stripping in protective door channels for added water protection
Venturo Crane Bodies include mudflaps
Double-panel lap-style 14-gauge Jet Kote ASTM A-60 steel doors

For more information regarding the Venturo line of crane bodies please call our sales team at 800-330-1229 or fill out our contact form.

Action customizes Venturo crane bodies which provide the optimum foundation for the crane and for your work truck. Venco Venturo manufacturers rugged and strong crane bodies.

Venturo HT40 Crane Service Body
The HT40 Crane Service Body supports the Venturo service cranes up to 40,000 FT-LBS on Class 4 (14,001 – 16,000 lbs GVWR) chassis. Product features:
Gutter-style drip rail above compartment doors for added water protection
Pre-installed front and rear outrigger cross-tubes with FULL STABILITY in all rotation zones
The substructure consists of a one-piece continuous longitudinal frame with integrated crane tower reinforcement up to 66,000 FT-LBS
Adjustable uni-strut shelf standards which allow greater flexibility for compartment loading
Pre-punched bottle vents

For more information regarding the Venturo line of crane bodies please call our sales team at 800-330-1229 or fill out our contact form.

Action customizes Venturo crane bodies which provide the optimum foundation for the crane and for your work truck. Venco Venturo manufacturers rugged and strong crane bodies.

HT25 Crane Service Body

 The HT25 Crane Service Body supports the Venturo service cranes up to 30,000 FT-LBS on Class 3 (10,001 – 14,000 lbs GVWR) chassis.
Product features:
Jet Kote ASTM A-60 steel construction
LED Stop/Turn/Tail/Backup, Marker and ID Lighting included with Wire Harness and Junction Box.  All bodies are designed with pre-punched light mounting holes for ease of installation
Optional workbench bumper with pass-through storage area and hinged doors with vice-plate
Fold-down, rear tailgate sized to the full width of the bed opening with right-hand and left-hand zinc plated tailgate latches and hinges
Stainless-steel spring-loaded door keepers hold doors open at 90 degrees and are self-closing

For more information regarding the Venturo line of crane bodies please call our sales team at 800-330-1229 or fill out our contact form.
